This GitHub repository contains the implementation of the Sheet Music Transfomrmer (SMT), a novel model for Optical Music Recognition (OMR) beyond monophonic level transcription. Unlike traditional approaches that primarily leverage monophonic transcription techniques for complex score layouts, the SMT model overcomes these limitations by offering a robust image-to-sequence solution for transcribing polyphonic musical scores directly from images.
If you plan to contribute, please read our Contributing Guidelines first. It contains information on how to set up the environment, coding conventions, how to submit pull requests, and how to write clear commit messages.
Feel free to open an issue if you have a question, idea, or discover a problem.
This project contains the uv Python dependencies manager. To start a new virtual environment, simply run:
uv syncIf you are using Docker to run experiments, create an image with the provided Dockerfile:
docker build -t <your_tag> .
docker run -itd --rm --gpus all --shm-size=8gb -v <repository_path>:/workspace/ <image_tag>
docker exec -it <docker_container_id> /bin/bashUsing the SMT for transcribing scores is very easy, thanks to the HuggingFace Transformers 🤗 library. Just implement the following code and you will have the SMT up and running for transcribing excerpts!
import torch
import cv2
from data_augmentation.data_augmentation import convert_img_to_tensor
from smt_model import SMTModelForCausalLM
image = cv2.imread("sample.jpg")
device = "cuda" if torch.cuda.is_available() else "cpu"
model = SMTModelForCausalLM.from_pretrained("<model_reference>").to(device)
predictions, _ = model.predict(convert_img_to_tensor(image).unsqueeze(0).to(device),
convert_to_str=True)
print("".join(predictions).replace('<b>', '\n').replace('<s>', ' ').replace('<t>', '\t'))Please, replace the <model_reference> with the implementation of the SMT it suits your purpose. Currently, this project hosts two models:
The datasets created to run the experiments are publicly available for replication purposes.
Eveything is implemented through the HuggingFace Datasets 🤗 library, so loading any of these datasets can be done through just one line of code:
import datasets
dataset = datasets.load_dataset('antoniorv6/<dataset-name>')The dataset has two columns: image which contains the original image of the music excerpt for input, and the transcription, which contains the corresponding bekern notation ground-truth that represents the content of this input.
These experiments run under the Weights & Biases API and the JSON config. To replicate an experiment, run the following code:
wandb login
uv run train.py --config_path <config-path>The config files are located in the config/ folder, depending on the executed config file, a specific experiment will be run.
You can make your own config files to train the SMT on your own data!
[!TIP] I highly recommend to use your datasets in the same format provided in the HuggingFace Datasets specification to work with this model. If not, I suggest to make your own data.py file from scratch. Please refer to the Data section to know how to structure your dataset.
Currently, the available model (SMT NeXt) reports the following metrics:
| Corpus | SMT NeXt | ||
|---|---|---|---|
| CER | SER | LER | |
| GrandStaff (Ideal) | 3.9 | 5.1 | 13.1 |
| GrandStaff (Camera) | 5.3 | 6.2 | 13.5 |
| Quartets | 1.3 | 1.4 | 5.6 |
@InProceedings{RiosVila:ICDAR:2024,
author="R{\'i}os-Vila, Antonio
and Calvo-Zaragoza, Jorge
and Paquet, Thierry",
title="Sheet Music Transformer: End-To-End Optical Music Recognition Beyond Monophonic Transcription",
booktitle="Document Analysis and Recognition - ICDAR 2024",
year="2024",
publisher="Springer Nature Switzerland",
address="Cham",
pages="20--37",
isbn="978-3-031-70552-6"
}This work is part of the I+D+i PID2020-118447RA-I00 (MultiScore) project, funded by MCIN/AEI/10.13039/501100011033. Computational resources were provided by the Valencian Government and FEDER funding through IDIFEDER/2020/003.
This work is under a MIT license.
